E5071C
758
No. Message Description
-
222
Data out
of range
A data element (not violating the standard)
outside the range defined by this instrument has
been received. This error occurs when an integer-
based command for which the parameter can be
rounded exceeds the range of -65536 to +65536
or when a real-number-based command for which
the parameter can be rounded exceeds the range
of -9.9e37 to +9.9e37, for example.
This error occurs also when a numeric value other
than a specified one is entered into a command in
which the "port number" and "CalKit number" are
specified as parameters and hence the parameters
are not rounded. Such commands are, for
example, CALC:FSIM:BAL:TOP:BBAL:PPOR,
SENS:CORR:COLL:ACQ:OPEN,
SENS:CORR:COLL:ECAL:SOLT3,
SENS:CORR:COLL:CKIT:ORD:LOAD, etc.
-
104
Data type
error
The parser has recognized a data element that
must not exist. Block data has been sent instead
of numeric value data or character string data that
had been expected, for example.
63
Duplicate
trace
name
This error occurs when a trace name defined with
CALCulate[1-160]:PARameter[1-16]:TNAMe:DATA
command already exist.
E
No. Message Description
32
ECal
module not
in
appropriate
RF path
This error occurs when an ECal command,
SENS:CORR:COLL:ECAL:SOLTn or
SENS:CORR:OFFS:COLL:ECAL:xxxx, is executed
with the port on the ECal module not connected
correctly to the instrument. When the auto-
detect function is turned OFF, (SENS:CORR:COLL
:ECAL:ORI OFF), however, this error does not
occur even when the port on the ECal module is
not connected correctly to the instrument.
502
Equation
run time
This error occurs under the following conditions:
