Product Information
759
error • The trace number in
data(tr)/mem(tr)/xAxis(tr) is out of range
# of trace available depends on the
maximum number of channel/traces
• The port number in Advanced math
function is out of range
# of port available depends on the model
option
-
200
Execution
error
An error associated with execution has been
generated for which this instrument cannot
specify the error message. This code shows that
an error associated with execution defined in
11.5.1.1.5, IEEE488.2 has occurred. This error
occurs also when a calibration measurement is
aborted.
-
123
Exponent
too large
The absolute value of the exponent exceeds
32,000 (see 7.7.2.4.1, IEEE488.2).
-
178
Expression
data not
allowed
An expression-data element has been received at
a position where this instrument does not accept
one.
-
170
Expression
error
When the expression data is put to syntactic
analysis, an error not corresponding to one of
Error Numbers -171 through -179 occurs.
27
External
test set
enabled
When the external test set mode is turned ON,
the allowable calibration is limited. See
Calibration and Measurement Parameters.
F
No. Message Description
31
Failed to
configure
ECal
module
This error occurs when the control of the ECal
module fails at time of executing an ECal
command, SENS:CORR:COLL:ECAL:SOLTn or
SENS:CORR:OFFS:COLL:ECAL :xxxx. The failure
results from the failure to connect the ECal
module to the USB port, failure of the ECal
module, etc.
76
Failed to
control
This error occurs when the external signal source
fails to respond during measurement, though it is
To Next Page
