Programming

1005

:SYST:BACK

Setting Display Color

Selecting Display Mode

You can select the one of two LCD display modes: normal display (black

background) or inverted display (white background).

To select the display mode, use the following command:

:DISP:IMAG

Setting display color for each item

To set the display colors, use the following commands:

Data trace

:DISP:COL{1-2}:TRAC{1-36}:DATA

Memory trace

:DISP:COL{1-2}:TRAC{1-36}:MEM

Graph

:DISP:COL{1-2}:GRAT{1-2}

Limit test

:DISP:COL{1-2}:LIM{1-2}

Background

:DISP:COL{1-2}:BACK

Resetting display colors to factory state

You can reset the display colors in normal display and inverted display to

the preset factory state.

To reset the display colors, use the following command:

:DISP:COL{1-2}:RES
