CCW-R-2**B INSTRUCTION MANUAL 5 REGISTERING OF PRODUCTS
5-21
<Section switching procedures>
• Section switching is available in the
[Item], [Product Setting] and [Weight
Setting] screens.
1. Press the [Section Select] drop-down key.
X The [Section Select] drop-down list appears.
Fig.5-29 [Product Setting] Index Screen
([Preset] Screen)
2. Press the key of the desired section.
X The [Preset] screen for the selected section
appears.
Fig.5-30 [Section Select] Drop-down List
([Preset] Screen)
3. Perform the settings by pressing the keys for the
desired items (tabs or indices).
Setting examples are shown in the following
section.
To return to the [Main Menu] screen, press the
[Exit] key .
Fig.5-31 [Product Setting] Index Screen
([Preset] Screen)
