3.2 Items and Functions of Remote Control Unit
This section describes the component names and functions of the remote control unit, using the figure
below.
Fig.3-1 Remote Control Unit Overview
Table 3-1 Descriptions of Remote Control Unit Functions
No. Name Function
1 Operation Panel Used to perform setting and displaying of the menu.
2 Printer Prints out the production summary and the setting details of individual
products.
3 Main power switch Turns the main power supply to the device ON/OFF.
4 Camera Takes photos of the products.
3
1
4
2
