CCW-R-2**B INSTRUCTION MANUAL 8 OPTIONAL FUNCTIONS
8-3
8.2.1.2 Bonus Adding
“Bonus adding” is a weighing method in which the parent head weight is not included into the target
weight (the parent head does not participate in the combination weighing).
The target weight for child heads will be the target weight of the device.
Target weight for child heads = Target weight
Example: When the target weight is 200.0g and the parent head weight is 30.5g:
200.0 + 30.5 = 230.5 (g)
The discharged product weight will be the sum of the combination weighing result with the child head
target weight of 200.0g, and the parent head weight.
For instance, when the combination weighing result of the child head is 200.5g, the discharged product
weight will be 200.5+30.5=231.0(g).
8.2.2 Setting Items of Parent and Child Weighing
The [Preset] screen is used to configure the parent and child weighing settings. Setting items for the
parent and child weighing are added to the [Preset] screen.
Refer to the following figure and table for setting items.
Fig.8-1[Prnt&Child Setting] Index Screen ([Preset] Screen)
Table 8-1 Items and Functions of [Prnt & Child Setting] Screen
No. Name Function
1 [Parent and Child] radio button Selects [On] or [Off] for the parent and child weighing.
[On]: Activates the parent and child weighing.
[Off]: The device performs normal weighing.
2 [Parent Head Count] radio button Sets “1” or “2” as the number of parent head(s).
3 [Parent Hd. Participation] radio
button
Selects [On] or [Off] for the participation of the parent head in the
combination weighing.
[On]: Switches into the parent and child mix weighing mode.
[Off]: Switches into the bonus adding mode.
