8 OPTIONAL FUNCTIONS CCW-R-2**B INSTRUCTION MANUAL
8-4
When the parent head count is set to “2”, the following items must be set to each parent head respectively.
When the parent head count is changed to “2” and the parent head setting is not yet completed, the parent
head setting index blinks to prompt you to complete the setting.
4 [Parent Zero Adjust] key Sets the interval to perform zero adjustment for the parent head.
0: Zero adjustment operation is not performed for the parent head.
Other than 0: Interval for the zero adjustment is set. The number of times that
the parent head discharges products is counted. For example, when “100” is
set as the interval, zero adjustment is performed in every 100 discharges from
the parent head.
• When the automatic zero adjustment interval is set
to “0” in the weigher specification setting screen,
the zero adjustment interval for the parent head
cannot be specified.
5 [Parent Dump Mode] radio button When the number of parent heads is set to “2”, selects discharging mode from
[Alternate] or [Simul.].
[Alternate]: Products are discharged first from P1 parent head and then from
P2 parent head.
[Simul.]: Each parent head discharges products simultaneously.
6 [Action Over Upper Limit] radio
button
Selects the action when the parent head weight exceeds the upper weight limit
that is described later in this section.
[PrntDump]: Discharges products from the parent head only.
[P & C Dump]: Discharges products from both parent head and child heads.
• If the parent head weight reaches the full scale, the
alarm buzzer sounds and the discharge operation is
not performed.
7 [Action Under Lower Limit] radio
button
Selects the action when the parent head weight falls below the lower weight
limit that is described later in this section.
[PrntDump]: Discharges products from the parent head only.
[Add’nl Feed]: Does not discharge products and supplies additional products.
• If the parent head weight is judged as an under scale,
the alarm buzzer sounds without supplying
additional products.
8 [Parent Head Setting] index Displays the [Parent Head Setting] screen.
Table 8-1 Items and Functions of [Prnt & Child Setting] Screen (Continued)
No. Name Function
To Next Page
