CCW-R-2**B INSTRUCTION MANUAL 13 APPENDIX
13-59
13.22 Connection Diagram
13.22.1 TOTAL DIAGRAM
13.22.2 BLOCK DIAGRAM
• The drawing is targeted for CCW-R-216B-D/**.
(1) CCW-R-216B-D/** 102-4577-05
102-4578-091
(1) REMOTE CONTROL UNIT 105-3851-04
(2) RELAY UNIT 107-2454-00
(3) AFV UNIT 107-2452-02
(4) ELECTRICAL UNIT 107-2459-08
(5) WEIGH DRIVE UNIT 107-2457-01
107-2458-04
(6) CAL UNIT 105-0490-021
105-3665-081
(7) POWER SUPPLY UNIT 102-3901-053
(8) POWER SUPPLY UNIT CE (1) 086-0964-073
(9) POWER SUPPLY UNIT CE (2) 108-7064-062
