CCW-R-2**B INSTRUCTION MANUAL 13 APPENDIX
13-15
13.6 Main Electrical Unit (CCW-R-224B)
13.6.1 Main Electrical Unit 1
Fig.13-13 Main Electrical Unit
Table 13-11 Names of Main Electrical Unit Parts
No. Name
1 HUB board (P-5535*)
2 FDRV board (P-5578*)
3 FDC board (P-5532*)
2
1
3124
2
3
1
AB
C
J544
XJ511-4
XJ512-4
