CCW-R-2**B INSTRUCTION MANUAL 10 MAINTENANCE AND INSPECTION
10-3
10.2.1.1 Dispersion table
For interference between the dispersion table and radial trough, check the circled portion shown in the
figure below.
Fig.10-1 Dispersion Table Partial View
10.2.1.2 Radial trough
For interference between the radial troughs, check the circled portion shown in figure below.
Fig.10-2 Radial Trough Partial View
Table 10-2 Names of Dispersion Table Parts
No. Name
1 Radial trough
2 Dispersion table
Table 10-3 Names of the Radial Trough Parts
No. Name
1 Radial trough
