13 APPENDIX CCW-R-2**B INSTRUCTION MANUAL
13-36
13.14 PS-2 Unit
Fig.13-34 PS-2 Unit
Functions of the unit
1. Power supply to the motor of the weigh drive unit.
• The number of the fuse boards may differ according to the number of heads in the machine.
Table 13-23 Names of PS-2 Unit Parts
No. Name
1 DC FUSE board (P-5508*)
2 DC39V switching power supply
11
2
2
2
