CCW-R-2**B INSTRUCTION MANUAL 13 APPENDIX
13-47
13.19 CAL Unit (CCW-R-224B)
Fig.13-45 CAL Unit
Table 13-30 Names of CAL Unit Parts
No. Name
1 ADC board (P-5576*)
2 WCU board (P-5561*)
3 DMU board (P-5562*)
4 Switching power supply for CAL unit (DC5V, ±15V)
9
7
8
5
6
12 3
4
