CCW-R-2** Ｂ INSTRUCTION MANUAL 4 OPERATION PROCEDURES
4-27
4.5.1.1 [Select Display] Pop-up Menu in [Combination] Screen
On the [Combination] screen, either the [Combination] or [Expansion Display] mode can be selected.
Press the [Select Display] pop-up key on the [Combination] screen, and select the desired display mode.
Fig.4-47 [Select Display] Pop-up Menu ([Combination] Screen)
Table 4-2 [Select Display] Pop-up Menu and Functions of the [Combination] Screen
No. Name Function
1 [Combination Display] key Selects the [Combination Result Display] screen.
Fig.4-48 [Combination Result Display] screen
