ISHIDA CCW-R-2 B Series - HUB Board (P-5535*)

13 APPENDIX CCW-R-2**B INSTRUCTION MANUAL
13-16
13.6.1.1 HUB Board (P-5535*)
Fig.13-14 HUB Board
Functions of the board
1. Relay and distribution of communication between WCU board, DUC board and FDC board via a
high-speed communication line.
• Check the suffix number when replacing the board.
