CCW-R-2**B INSTRUCTION MANUAL 13 APPENDIX
13-45
13.18.3 DMU Board (P-5562*)
Fig.13-44 DMU Board
Functions of the board
1. Data processing.
2. Storing of total data and parameters.
3. Communication with the remote control BOX unit (RCU board) by a high-speed communication
line.
SW4-3 ON
SW4-4 OFF
Table 13-28 Setting Items of DIP-SW (Continued)
DIP-SW Setting
SW1
SW2
SW3 BATTERY
