CCW-R-2**B INSTRUCTION MANUAL 9 CLEANUP PROCEDURES
9-15
9.4.2 Cleaning the Unremovable Unit
Fig.9-16 Unremovable Unit and Parts
Table 9-10 Unremovable Unit and Parts List
No. Name Reference
1 Rubber cover of the dispersion feeder 9.4.2.1 Main Body, Dispersion Portion, and Drive Unit
2 Rubber cover of the radial feeder 9.4.2.1 Main Body, Dispersion Portion, and Drive Unit
3 Drive unit 9.4.2.1 Main Body, Dispersion Portion, and Drive Unit
4 Main body 9.4.2.1 Main Body, Dispersion Portion, and Drive Unit
5 Remote control unit 9.4.2.2 Remote Control Unit
1 22
3
4
5
