13 APPENDIX CCW-R-2**B INSTRUCTION MANUAL
13-10
13.5 Main Electrical Unit
Fig.13-8 Main Electrical Unit
• The drawing is an example of CCW-R-216B-D.
Table 13-9 Names of Main Electrical Unit Parts
No. Name
1 HUB board (P-5535*)
2 MPS board (P-5436*)
3 FDRV board (P-5578*)
4 FDC board (P-5532*)
3
4
2
1
