CCW-R-2**B INSTRUCTION MANUAL 11 CAUSES AND ACTIONS FOR ERRORS AND FAILURES
11-3
11.2 Error Display and Action
If an error occurs during operation, draining, or zero adjustment, an error message is displayed on the
screen of the remote control unit.
There are eight error message screen patterns depending on the display method, alarm sound or weighing
machine status. ( Table 11-1 Error Screen Patterns )
Actions for errors differ depending on the error screen pattern. Check the screen pattern of the error and
refer to details of each pattern described in “11.2.1 Pattern 1” through “11.2.8 Pattern 8”, to cancel the
error display and perform the correcting action.
Table 11-1 Error Screen Patterns
Error Screen Pattern Error Name weighing machine
Condition
Pattern 1 • [ZERO ERROR] (Auto zero adjustment)
• [OVERWEIGHT ERROR]
• [OVERSCALE ERROR]
• WH, PH, RS, TH, and DTH ERROR
• [PIECE WEIGHT ERROR] (Count set weighing
specification)
• Error alarm sounds
• Operation stops
11.2.1 Pattern 1
Pattern 2 • [ZERO ERROR] (Manual zero adjustment)
• [SPAN ERROR]
• [NETWORK ERROR]
• [RECHECK ERROR] (Count set weighing specification)
• [FDRV ERROR]
• Error alarm sounds
• Operation stops
11.2.2 Pattern 2
Pattern 3 • [WARNING: NO TRANSMISSION]
• [WARNING: NO RESPONSE]
• [LOW PRODUCT]
• [WARNING: OVERSCALE]
• [WARNING: DETACHED HEAD]
• [WARNING: OVERWEIGHT ERROR]
• [RCU fan stopped. Contact to factory service.]
• [WARNING: AUTO ZERO ERROR]
• [WARNING: COMMUNICATION ERROR]
• [WARNING: RECHECK ERROR]
• WARNING: PH, WH, and BH ERROR
• Error alarm sounds
11.2.3 Pattern 3
Pattern 4 • [The memory of <Product Set> may be corrupt.]
• [The memory of <Weigh Spec. Set> may be corrupt.]
• [The memory of <Combi.Calc.Spec.Set> may be corrupt.]
• [The memory of <Sectioning Method Setting> may be
corrupt.]
• [The memory of <Infeeder Control SET> may be corrupt.]
• [The memory of <Packer Interlock Setting> may be
corrupt.]
• [COPY / Initialize error]
• Warning alarm
• Operation stops
11.2.4 Pattern 4
This error is displayed only
when weighing machine
operation is stopped.
Pattern 5 • [AFV ZERO ERROR]
• [AFV PARAMETER ERROR]
• [AFV COMPENSATION ERROR]
• [AFV OUTPUT ERROR]
• [AFV OVERFLOW ERROR]
• Error alarm sounds
• Operation stops
• Power OFF
11.2.5 Pattern 5
Pattern 6 • [Total Overflow!] • Error alarm sounds
• Operation stops
11.2.6 Pattern 6
