9 CLEANUP PROCEDURES CCW-R-2**B INSTRUCTION MANUAL
9-10
9.4.1.3 Radial Trough
• Remove the radial troughs after removing the pool hoppers.
1. Pull up the clamp lever at the bottom of the
radial trough, and remove the radial trough.
2. After washing and sterilizing, rinse with water
and dry. (For the washing and sterilization
methods, refer to “Table 9-5 Washing and
Sterilization Methods of Radial Trough”)
Fig.9-7 Radial Trough Removal
3. Reinstall in the reverse order of the removal.
4. Make sure the radial troughs are not touching
each other.
5. If there is any contact, repeat reinstallation so
that they do not touch each other.
Fig.9-8 Radial Trough Installation
Table 9-5 Washing and Sterilization Methods of Radial Trough
Washing method Immersion cleaning (Neutral detergent)
Sterilization method Immersion sterilization
Warm water (80 to 90 deg C): 30 minutes.
Or,
sodium hypochlorite (available chlorine concentration 250): 20 minutes.
