CCW-R-2**B INSTRUCTION MANUAL 13 APPENDIX
13-17
13.6.1.2 FDRV Board (P-5578*)
Fig.13-15 FDRV Board
Functions of the board
1. Drive control of the radial feeder.
2. Relay and distribution of power supply from PS feeder unit to radial feeder.
• Check the suffix number when replacing the board.
