CCW-R-2**B INSTRUCTION MANUAL 9 CLEANUP PROCEDURES
9-13
9.4.1.6 Discharge Chute
• Remove the discharge chute after removing the collection chute.
• Removal procedures of the discharge chute differ depending on the devices.
1. Lift up the discharge chute, and remove
between the legs.
For the type that the discharge chute cannot be
removed between the legs, remove the timing
hopper first, and then remove the discharge
chute from underneath. ( 9.4.1.7 Timing
Hopper)
2. After washing and sterilizing, rinse with water
and dry. (For the washing and sterilization
methods, refer to “Table 9-8 Washing and
Sterilization Methods of Discharge Chute”)
3. Reinstall in the reverse order of the removal.
4. Make sure the discharge chute is installed
securely.
Fig.9-13 Discharge Chute Removal
Table 9-8 Washing and Sterilization Methods of Discharge Chute
Washing method Immersion cleaning. (Neutral detergent)
Sterilization
method
Immersion sterilization.
Warm water (80 to 90 deg C): 30 minutes.
Or,
sodium hypochlorite (available chlorine concentration 250 ppm): 20 minutes.
