CCW-R-2**B INSTRUCTION MANUAL 13 APPENDIX
13-37
13.15 PS-2 Unit (CCW-R-224B)
Fig.13-35 PS-2 Unit
Functions of the unit
1. Power supply to the motor of the weigh drive unit.
Table 13-24 Names of PS-2 Unit Parts
No. Name
1 DC FUSE board (P-5508*)
2 DC39V switching power supply
1
2
11
2
