CCW-R-2**B INSTRUCTION MANUAL 12 INSTALLATION
12-5
12.3.3 Weight of Device, Center of Gravity, and Dimensions
The center of gravity of the weighing machine is as follows.
• For details such as the weight and dimensions of the weighing machine, refer to the
specifications issued for the contract, or contact the distributor or Ishida customer support.
When lifting the weighing machine, use an appropriate lifting weighing machine in
accordance with the weighing machine weight, and take into account the center of gravity of
the load when lifting.
Fig.12-1 Lifting Diagram
Hc
Lc
G(=Lc/2)
