ISHIDA CCW-R-2 B Series - Inspection of Open;Close for Hopper Gate (Monthly)

10 MAINTENANCE AND INSPECTION CCW-R-2**B INSTRUCTION MANUAL
10-12
10.3.3 Inspection of Open/Close for Hopper Gate (Monthly)
1. Remove the pool hopper, weigh hopper, and
booster hopper.
Fig.10-17 Pool Hopper Removal
Fig.10-18 Weigh Hopper Removal
Fig.10-19 Booster Hopper Removal
BOOSTER HOPPER
OPEN/CLOSE
LEVER
