13 APPENDIX CCW-R-2**B INSTRUCTION MANUAL
13-18
13.6.1.3 FDC Board (P-5532*)
• When replacing the board, set the DIP-SW to the setting as it was before the replacement.
Fig.13-16 FDC Board
Functions of the board
1. Drive control of the radial feeder.
Setting of the board switches
• When replacing the board, set as it was before the replacement.
Table 13-12 Setting Items of DIP-SW
DIP-SW Setting
SW 1-1 OFF
SW 1-2 OFF
SW 1-3 OFF
SW 1-4 OFF
