CCW-R-2**B INSTRUCTION MANUAL 6 FUNCTIONS OF THE OPERATION SCREENS
6-101
6.13.1 Switching Display in [Feeder Adjust] Screen
The [Feeder] pop-up menu appears when the [Feeder] pop-up key is pressed in the [Feeder
Adjust] tab screen. From the [Feeder] pop-up menu, the screen can be switched to any of the following
displays: production status information, feeder circle graph, feeder bar graph and AFD setting.
1. Press the [Feeder] pop-up key .
X The [Feeder] pop-up menu appears.
Fig.6-99 [Feeder Adjust] Tab Screen
([Production] Screen)
2. Select the item to be displayed from the list
below.
Fig.6-100 [Feeder] Pop-up Menu
([Production] Screen)
