6 FUNCTIONS OF THE OPERATION SCREENS CCW-R-2**B INSTRUCTION MANUAL
6-102
Table 6-46 Displays of [Feeder] Pop-up Menu
No. Name Function
1 [Production status information] key Displays the AFD status and production status.
Fig.6-101 Production Status Information
2 [Circle graph display] key Displays the feeder value in a circle graph.
Fig.6-102 Circle Graph
3 [Bar graph display] key Displays the feeder value in a bar graph.
Fig.6-103 Bar Graph
