ISHIDA CCW-R-2 B Series - Base Unit Feeder; Preamp Board (P-5435*)

13 APPENDIX CCW-R-2**B INSTRUCTION MANUAL
13-22
13.7 Base Unit Feeder
13.7.1 Preamp Board (P-5435*)
Fig.13-20 Preamp Board
Functions of the board
1. Amplification of the dispersion feeder load cell output.
• Check the suffix number when replacing the board.
