CCW-R-2**B INSTRUCTION MANUAL 13 APPENDIX
13-41
13.17 Booster Hopper Drive Unit
13.17.1 DU Board (P-5429*)
Fig.13-39 DU Board
Functions of the board
1. Driving the motor for opening/closing the booster hopper.
13.17.2 Cam Sensor Board (P-5207*)
Fig.13-40 Cam Sensor Board
Functions of the board
1. Detects the booster hopper stop position using the cam with slit and sends the signal to the DUC
board.
