5.3.2 Outline of the Registration
This section describes the outline of the product registration for the mix weigher.
Refer to “5.3.3 Preset Procedures” for details regarding the operation procedures.
For the mix weigher, there are some setting items that apply to the whole mix weigher, and some that
apply to each section.
For items marked with * in the following chart, respective initial values are registered. Refer to “5.3.1
Registration Details” for each initial value.
Refer to “5.3.1 Registration Details” for detailed descriptions of all items in the following chart.
Selecting the machine ( 5.3.3.1 Selecting the Machine)
↓
Selecting the section ( 5.3.3.2 Selecting the Section)
↓
Setting the product ( 5.3.3.3 Setting the Product)
Product name, product code, product category, selecting photos*, and taking photos*
↓
Setting the machine*
Speed, dump count, average control, interlock parameter number, and section parameter number
↓
Setting the item*
Auto feed target, disch. priority count, good efficiency judgement value, feed multiplier, hopper action
parameter number, photo SW, and shutter drive
↓
Other settings*
Stable time and BH non sync feeding
↓
Setting the weighed product ( 5.3.3.4 Setting the Weighed Product)
Product name, product code, and mix topping method
↓
Setting the feeder value*
↓
Setting the timing value*
↓
Setting the weight value ( 5.3.3.5 Setting the Weight Value)
Target weight, extended upper limit, upper weight limit, lower weight limit,
and extended upper limit dump cycle
↓
Completing the setting operation
