5 REGISTERING OF PRODUCTS CCW-R-2**B INSTRUCTION MANUAL
5-16
Timing Adjustment Sets the timing value for the opening/closing
of each hopper.
• WH-DS: 0
•IS-WH: 0
• WH-PH: 190
• PH-RF: 130
• WH DELAY: 0
• Stagger: 0
•WH-BH: 60
• BH-WH: 100
• WH ON: 450
• BH ON: 400
• PH ON: 400
• WH-DS: 0
•IS-WH: 0
• WH-PH: 190
• PH-RF: 130
• WH DELAY: 0
• Stagger: 0
•WH-BH: 60
• BH-WH: 100
• WH ON: 450
• BH ON: 400
• PH ON: 400
Target weight Sets the product weight to be discharged
from the selected section to the packer.
S1: 0, S2: 0 S1: 60, S2: 60
Extended Upper Limit Sets the tolerance so that products can be
discharged as proper weight even if the
upper limit is exceeded once in a specified
number of proper weight dumps of the
selected section.
Constant cycle means the extended upper
limit dump cycle.
00
Upper Weight Limit Sets the upper limit of the proper weight for
the selected section.
S1: 0, S2: 0 S1: 5, S2: 5
Lower Weight Limit Sets the lower limit of the proper weight in
grams when the average control function is
utilized for the selected section or when mix
weighing is performed.
S1: 0, S2: 0 S1: 0, S2: 0
Table 5-2 Preset Details (Continued)
