CCW-R-2**B INSTRUCTION MANUAL 5 REGISTERING OF PRODUCTS
5-15
Speed Sets the number of packs to be discharged
from the device per minute.
60 60
Dump Count Divides and discharges the product
separately to prevent the product from
jamming in the packer when the target
weight is large or when a product will
overflow if weighed all at once. The number
of times for division is set here.
11
Average Control Controls the target weight at a regular
interval in order to maintain the discharged
weight mean value to be close to the target
weight. You can select [On] or [Off] for this
function.
Off Off
Interlock Parameter
Number
Selects the interlock mode between the
device and the packer.
11
Section Parameter
Number
Selects the section division pattern when
dividing weigh heads into sections and
weighing different products in each section.
There are up to eight different division
patterns.
2
(Single weighing of S1)
1
(Double mix weighing of
S1 and S2)
Auto Feed Target Sets the number of weigh hopper heads to be
selected for discharge operation in order to
obtain the target weight set for the selected
section.
S1: 3.8, S2: 3.8 S1: 3.8, S2: 3.8
Disch.Priority Count Sets the number of times to give priority in
participating in the combination to heads in
the selected section that have not discharged
the product.
S1: 30, S2: 30 S1: 30, S2: 30
Good Efficiency
Judgement Value
Sets the efficiency rate judged as good
condition.
99.0 99.0
Feed Multiplier Sets the multiplying factor of feeder
operating time set in the [Feeder
Adjustment] screen of the selected section.
S1: 1, S2: 1 S1: 1, S2: 1
Hopper Drive Setting Selects parameters to set the open/close
operation condition for each hopper of the
selected section including the pool hopper
and weigh hopper.
S1: 1, S2: 1 S1: 1, S2: 1
Photo SW Selects [On] for models with a photo eye
sensor, and [Off] for models without a photo
eye sensor.
Off Off
Shutter Drive Selects [On] for models with a shutter drive,
and [Off] for models without a shutter drive.
Off Off
Feeder Adjustment Sets operating intensity of the radial and
dispersion feeders, operating time, and
dispersion weight. Adjusts the product feed
to the pool hopper, radial trough, and
dispersion table based on the set value.
• AFD mode: Manual
•AMP: 50
•Time: 25
• Target Wt: 500
• AFD mode: Manual
•AMP: 30
•Time: 25
• Target Wt: 300
Table 5-2 Preset Details (Continued)
Setting Item Setting Detail Initial Value Setting Example
