6 FUNCTIONS OF THE OPERATION SCREENS CCW-R-2**B INSTRUCTION MANUAL
6-82
6.12 [Select Total] Pop-up Menu
To display the [Select Total] pop-up menu, press the [Select Total] pop-up key on the [Main Menu]
screen.
From the displayed keys, select the total data to be displayed.
Fig.6-85 [Select Total] Pop-up Menu
Table 6-37 Keys and Functions of [Select Total] Pop-up Menu
No. Name Function
1 [Current Total] key Displays the total and histogram for the period from all total clear to the
present.
2 [X-bar Chart] key Displays the X-bar chart.
3 [Weigher’s Transitional Data] key Displays the operational transition data of the weigher.
4 [Per Head - Cmb. Participation Data]
key
Displays the status of each head.
5 [Total Setting] key Displays the [Total Setting] screen.
6 [Operation Log] key Displays the operation log.
