ISHIDA CCW-R-2 B Series - Setting the Weighed Product

CCW-R-2**B INSTRUCTION MANUAL 5 REGISTERING OF PRODUCTS
5-25
5.3.3.4 Setting the Weighed Product
The term “weighed product” here refers to the individual weighed goods that compose the product.
• When there is only one section, the [Section Select] drop-down key and the [Product Setting]
index are not displayed on the screen. Select the section parameter number with the [Section
Parameter Number] drop-down key in the [Machine] tab. ( 5.3.3.2 Selecting the Section)
1. Press the [Product Setting] key in the index.
X The [Product Setting] screen appears.
Fig.5-39 [Product] Tab Screen ([Preset] Screen)
2. Press the [Product Name] key .
X The [Keyboard] screen appears.
Fig.5-40 [Product Setting] Index Screen
([Preset] Screen)
