CCW-R-2**B INSTRUCTION MANUAL 12 INSTALLATION
12-9
12.4.4 Connecting Power Cable and Remote Control Unit
After installing the weighing machine to the predetermined location, perform wire routing and
installation position adjustment of the remote control unit in accordance with the following procedures.
• Connecting work between the weighing machine and the power supplies
should be performed by a licensed electrician in accordance with the national
and local electrical regulations.
• Before connecting to the plant power terminal, use a tester to check if the
power specifications of the weighing machine match with the plant power
supply.
When power of different specifications is accidentally supplied, serious
damage to the weighing machine may occur.
1. Fix the main power switch in accordance with the following procedures.
a. Install the fixing metallic fitting (E) of the main power switch to the base metallic part of the
remote control unit (A), using two screws (E1).
b. Fix the main power switch (B) to the fixing metallic fitting (E), using two screws (E2).
2. Adjust the remote control unit angle in accordance with the following procedures.
a. Fix the installation bracket (D) of the remote control unit to the specified position, using four
screws (D1).
b. Adjust the remote control unit to an easily viewable angle, using the knob bolts (D3) and angle
adjustment screws (D2), and fix it in the position.
• Before connecting to the plant power terminal, make sure that the electricity
is shut off, and then connect the power cable (H) to the plant power terminal.
Before connecting to the plant power terminal, connect the remote control
cable (F) and the power cable (G). Make sure that the power circuit breaker of
the weighing machine is turned OFF.
3. Guide the power cable (G) inside of the main body frame, and fix the flexible tube to the main body
frame.
4. Connect the power cable (G) to terminals L11 and L31 of the terminal block XT601.
5. Guide the remote control cable (F) inside of the main body frame, and fix the flexible tube to the
main body frame.
6. Connect the communication cable XJ02 of the remote control cable (F) to the relay connector of the
CAL unit located in the main body frame.
