5 REGISTERING OF PRODUCTS CCW-R-2**B INSTRUCTION MANUAL
5-2
5.2 Presetting the Double Weigher
This section describes the preset procedures when this device is used as a double weigher.
5.2.1 Registration Details
Items and details to be set in the preset screen are described in “Table 5-1 Preset Details”.
• Each set value differs depending on product type, characteristics and setting
environments. Perform the actual adjustment while checking the operation
status.
• “Initial Value” in “Table 5-1 Preset Details” is the standard value (default value) set to the device in advance.
• “Setting Example” is the example when weighing 90g of potato chips as a normal size and 120g of potato chips
as a large size. ( 5.2.3 Preset Procedures)
Table 5-1 Preset Details
Setting Item Setting Detail Initial Value Setting Example
CH.Select Selects either double weighing or mix
weighing for the production type.
— Double (C1 + C2)
Product name Sets the product name. — C1: Potato chips
C2: Potato chips (large)
Product code Sets the product code. — 01
Product Category Sets the desired product category. — A100
Photo Selection Selects the photo. When there is no photo
data, is displayed.
Camera Takes photos of the products. — —
Speed Sets the number of times that the weighing
operation is performed per minute.
60 70
Dump Count Divides and discharges the product
separately to prevent the product from
jamming in the packer when the target
weight is large or when a product will
overflow if weighed all at once. The number
of times for division is set here.
11
Average Control Controls the target weight at a regular
interval in order to maintain the discharged
weight mean value to be close to the target
weight. Select [On] or [Off] for this
function.
Off Off
