CCW-R-2**B INSTRUCTION MANUAL 5 REGISTERING OF PRODUCTS
5-3
Interlock Parameter
Number
Selects the interlock mode between the
device and the packer.
There are four different interlock modes.
11
Section Parameter
Number
Selects the section division pattern when
dividing weigh heads into sections and
weighing different products in each section.
There are eight different division patterns.
22
Auto Feed Target Sets the number of weigh hopper heads to be
selected for discharge operation in order to
obtain the target weight.
3.8 3.8
Disch.Priority Count Sets the number of times to give priority in
participating in the combination to heads
that have not discharged the product.
30 30
AFD Auto adjustment
limit amp
Sets the range where the operating intensity
is automatically adjusted when the AFD is
set to “Auto”.
——
AFD Auto adjustment
limit time
Sets the range where the operating time is
automatically adjusted when the AFD is set
to “Auto”.
——
Feed Multiplier Sets the multiplying factor of feeder
operating time set in the [Feeder
Adjustment] screen.
11
Hopper Drive Setting Selects parameters to set the open/close
operation condition for each hopper
including the pool hopper and weigh hopper.
00
Photo SW Selects [On] for models with a photo eye
sensor, and [Off] for models without a photo
eye sensor.
Off Off
Shutter Drive Selects [On] for models with a shutter drive,
and [Off] for models without a shutter drive.
Off Off
Feeder Adjustment Sets operating intensity of the radial and
dispersion feeders, operating time, and
dispersion weight. Adjusts the product feed
to the pool hopper, radial trough, and
dispersion table based on the set value.
• AFD mode: Manual
•AMP: 50
• Time: 25
• Target Wt: 500
• AFD mode: Manual
•AMP: 50
•Time: 25
• Target Wt: 500
Timing Adjustment Sets the timing value for the opening/closing
of each hopper.
•IS-DS: 0
• IS-TH1: 0
•IS-WH: 0
• WH-PH: 190
• PH-RF: 130
• Stagger: 0
•WH-BH: 60
• BH-WH: 100
•IS-DS: 0
• IS-TH1: 0
•IS-WH: 0
• WH-PH: 190
• PH-RF: 130
• Stagger: 0
•WH-BH: 60
• BH-WH: 100
Target weight Sets the product weight to be discharged
from the device to the packer.
C1: 0
C2: 0
C1: 90
C2: 120
Extended Upper Limit Sets the tolerance so that products can be
discharged as proper weight even if the
upper limit is exceeded once in a specified
number of proper weight dumps.
00
Table 5-1 Preset Details (Continued)
Setting Item Setting Detail Initial Value Setting Example
