CCW-R-2**B INSTRUCTION MANUAL 13 APPENDIX
13-21
13.6.2.2 Preamp Board (P-5435*)
Fig.13-19 Preamp Board
Functions of the board
1. Amplification of the dispersion feeder load cell output.
• Check the suffix number when replacing the board.
