9 CLEANUP PROCEDURES CCW-R-2**B INSTRUCTION MANUAL
9-12
9.4.1.5 Collection Chute
• Install the collection chute after installing the discharge chute.
4. After washing and sterilizing, rinse with water
and dry. (For the washing and sterilization
methods, refer to “Table 9-6 Washing and
Sterilization Methods of Pool Hopper, Weigh
Hopper, and Booster Hopper”)
• When the radial troughs are removed,
install them first.
5. Reinstall in the reverse order of the removal.
6. Make sure the roller of each hopper fits into the
switching lever.
7. If not, install it again.
Table 9-6 Washing and Sterilization Methods of Pool Hopper, Weigh Hopper, and Booster Hopper
Washing method Immersion cleaning. (Neutral detergent)
Sterilization method Immersion sterilization.
Warm water (80 to 90 deg C): 30 minutes.
Or,
sodium hypochlorite (available chlorine concentration 250 ppm): 20 minutes.
1. Pull up the collection chute upper portion, and
lift up to remove.
2. After washing and sterilizing, rinse with water
and dry. (For the washing and sterilization
methods, refer to “Table 9-7 Washing and
Sterilization Methods of Collection Chute”)
3. Reinstall in the reverse order of the removal.
4. Make sure that the collection chute is securely
installed.
Fig.9-12 Collection Chute Removal
Table 9-7 Washing and Sterilization Methods of Collection Chute
Washing method Immersion cleaning. (Neutral detergent)
Sterilization
method
Immersion sterilization.
Warm water (80 to 90 deg C): 30 minutes.
Or,
sodium hypochlorite (available chlorine concentration 250 ppm): 20 minutes.
