13 APPENDIX CCW-R-2**B INSTRUCTION MANUAL
13-46
DIP-SW settings
• Refer to “10.3.8 Replacement of Memory Backup Battery” for replacing
battery.
Table 13-29 Setting Items of DIP-SW
DIP-SW Function Default Setting
SW1-1 ON: Models with two distributed cameras
OFF: Models with one distributed camera
OFF
SW1-2 ON: Models with no camera
OFF: Models with camera
OFF
SW1-3 to SW1-8 Not used OFF
SW2-1 to SW2-5 Not used OFF
SW2-6 ON: Clears SRAM when initializing memory
OFF: Does not clear SRAM when initializing memory
OFF
SW2-7 ON: Does not output FIF0 at DMU application
OFF: Outputs FIF0 at DMU application
OFF
SW2-8 ON: Does not output boot loader message
OFF: Outputs boot loader message
OFF
SW3-1 ON: Boot loader mode
OFF: Application execution mode
OFF
SW3-2 Fix to OFF and should no be turned ON. OFF
SW3-3 ON: Writing data to flash memory is prohibited.
OFF: Writing data to flash memory is allowed.
OFF
SW3-4 Fix to OFF and should no be turned ON. OFF
