6 FUNCTIONS OF THE OPERATION SCREENS CCW-R-2**B INSTRUCTION MANUAL
6-54
3. Mix weigher only) Press the head number to be
operated.
X All heads of the section containing the
selected head are selected.
Pressing the [All Section] key will
select all sections.
Fig.6-59 [Section Select] Pop-up Menu
([Full Open Lock] Screen, Mix Weigher)
4. (Mix weigher only) Press the [Section Select]
pop-up key.
X The [Section Select] pop-up menu closes.
Fig.6-60 [Section Select] Pop-up Menu
([Full Open Lock] Screen, Mix Weigher)
5. Press the [Open] key .
X The specified hoppers are held open. Or, the
specified feeder starts to operate.
• Feeder amplitude conforms to the
settings in the feeder adjustment
( 6.13 [Feeder Adjustment]
Screen).
Fig.6-61 [Unit Select] Tab Screen
([Full Open Lock] Screen)
