CCW-R-2**B INSTRUCTION MANUAL 6 FUNCTIONS OF THE OPERATION SCREENS
6-159
• The number of RS parameters that can be set is as follows:
• For the minimum weight head number, the maximum weight head number, the pool in multi
dump and the cycle pool, 8 patterns can be set for each parameter of packer interlock setting
(32 patterns in total).
• For the EXC number, the EXC port number, the discharge direction and the product hold
step, a pattern can be set for each parameter of packer interlock setting (4 patterns in total).
The pooling operation depends on the combination of multi dump and cycle as shown below.
• A cycle refers to a series of process from weighing to dump.
For example, when the dump count is set to “3” for multiple dump weighing, 3 cycles make 1 weighing
(corresponding to the target weight).
When the dump count is “1”, 1 cycle makes 1 weighing.
10 [Discharge Direction] radio button Selects the discharge direction between [Prper:Side1] and [Error:Side2].
11 [Product Hold step] key Sets the number of steps seen from WH using the [Numeric Keypad] screen.
Setting range: 0-8.
Table 6-77 Combination of Multi Dump and Cycle
Pool in Multi
Dump
Cycle Pool Operation
[Off] [Off] Products are not pooled.
[Off] [On] Products of amount for 1 cycle are pooled but not for 1 weighing (multiple
dumps).
[On] [On] Products of amount for 1 weighing (multiple dumps).
[On] [Off] -
Table 6-76 Items and Functions of the [RingShutter] Index Screen (Continued)
No. Name Function
