8 OPTIONAL FUNCTIONS CCW-R-2**B INSTRUCTION MANUAL
8-8
3. Press the [Parent and Child] radio button and
select [On].
4. Press the [Parent Head Count] radio button and
select [1] or [2].
5. Press the [Parent Hd. Participation] radio
button and select [On] or [Off].
6. Press the [Parent Zero Adjust] key
, and input the numerical value
with the [Numeric Keypad] screen displayed on
the screen.
7. Press the [Parent Dump Mode] radio button and
select [Alternate] or [Simul.].
8. Press the [Action Over Upper Limit] radio
button and select [PrntDump] or [P & C
Dump].
9. Press the [Action Under Lower Limit] radio
button and select [PrntDump] or [Add’nl Feed].
Fig.8-5 [Prnt&Child Setting] Index Screen
([Preset] Screen)
10. Press the [Parent Head Setting] key in the
index.
X The [Parent Head Setting] screen appears.
• When the number of parent heads is set to [2],
the [Parent Head Selection] drop-down key
appears.
Fig.8-6 [Prnt&Child Setting] Index Screen
([Preset] Screen)
