CCW-R-2**B INSTRUCTION MANUAL 8 OPTIONAL FUNCTIONS
8-13
• In count set weighing, after the combination weighing is completed, the weighing result is
checked to see if it is within “target weight + upper weight limit” and “target weight - lower
weight limit”.
Products will not be discharged if the value is not within this range, so care must be taken in
setting upper and lower weight limits. A setting example is shown below.
Example: When the target count is 10, the upper count limit is 1, and the piece weight is
5.00g (4.80 to 5.20g)
Target weight: 50g (5.00 × 10)
Lower weight limit: 2g (50.0 - 4.80 × 10)
Upper weight limit: 7.2g (5.20 × 11 - 50.0)
4 [Piece Weight] key Sets the weight for a single piece of product.
The number of pieces supplied to each hopper is calculated based on this piece
weight value.
5 [Piece Weight Revision] radio button Specifies whether the device automatically updates the piece weight ([1/1], [1/
2], [1/4]) or not ([Off]).
When set to [Off], the number of pieces supplied to each weigh hopper is
calculated based on the specified piece weight value.
When the piece weight varies, set this field to perform update so that the piece
weight is automatically updated and the number of pieces supplied to each
weigh hopper is calculated based on the updated piece weight value.
Furthermore, there are three options for the update setting ([1/1], [1/2], and [1/
4]) depending on the range to which the updated operation can be performed.
Set this option to [1/1] in normal operation.
[1/1]: Use this option if no error occurs in converting to the number of pieces
when the target amount of product is supplied to one head.
[1/2]: Use this option if no error occurs in converting to the number of pieces
when half of the target amount of product is supplied to one head.
[1/4]: Use this option if no error occurs in converting to the number of pieces
when one quarter of the target amount of product is supplied to one head.
• Refer to “8.3.2 Piece Weight Revision” for details regarding the
piece weight update.
Table 8-5 Items and Functions of [Count Setting] Index Screen (Continued)
No. Name Function
Target Count Upper Count
10 Piece 11 Piece
Target LimitLower Limit
Upper Limit
-2.0g 50.0g +7.2g
To Next Page
