CCW-R-2**B INSTRUCTION MANUAL 2 INTRODUCTION
2-5
Master mode A mode in which, when this device is interlocked with the packer, it discharges upon receiving
a (continuous) signal from the packer.
Slave mode A mode in which, when this device is interlocked with the packer, it discharges upon receiving
a one shot signal from the packer.
Stroke On Demand mode A mode in which, when this device is interlocked with the packer, it discharges by transmitting
a weighing completion signal to the packer, while in response the packer transmits an interlock
signal.
Bag On Demand mode A mode in which, when this device is interlocked with the packer, self-calculation is
performed until the device discharges a proper amount of product based on a signal from the
packer, and a discharge completion signal is transmitted to the packer.
AFV Stands for Anti Floor Vibration mechanism.
With this function, even in a floor vibration environment, the AFV cell detects vibrations, and
errors caused by the vibration can be canceled from the load cell output for weighing.
Range The maximum weight that can be weighed.
Auto zero adjustment To automatically adjust weight during operations after selecting a head with less operation
frequency among the combinationally selected weigh hoppers, so that the weight display
indicates zero.
Preset Product data on weighing, registered in advance.
Combination A calculation method where small-divided, several weighed values are combined, and the
most favorable combination is used as a weighed value to be discharged.
Full scale A condition where the weighing sensor value exceeds a permissible load due to external
factors.
Multiple dump weighing A weighing method where the target weight is obtained through multiple dumps, when a large
amount of product exceeding the weighing range is weighed or when a product overflows
from the weigh hopper if weighed all at once.
Table 2-1Term Descriptions (Continued)
Term Description
To Next Page
