CCW-R-2**B INSTRUCTION MANUAL 13 APPENDIX
13-51
• Refer to “10.3.8 Replacement of Memory Backup Battery” for replacing
battery.
SW2-7 ON: Does not output FIF0 at DMU application
OFF: Outputs FIF0 at DMU application
OFF
SW2-8 ON: Does not output boot loader message
OFF: Outputs boot loader message
OFF
SW3-1 ON: Boot loader mode
OFF: Application execution mode
OFF
SW3-2 Fix to OFF and should no be turned ON. OFF
SW3-3 ON: Writing data to flash memory is prohibited.
OFF: Writing data to flash memory is allowed.
OFF
SW3-4 Fix to OFF and should no be turned ON. OFF
Table 13-33 Setting Items of DIP-SW (Continued)
DIP-SW Function Default Setting
