Planet SGS-6341-24T4X User Manual

66-2
<session>: session ID, range between 1~7. <vid>: The id of RSPAN VLAN.
Command Mode:
Global Mode.
Default:
Not configured.
Usage Guide:
To configure local mirror session to RSPAN. The VLAN id is the RSPAN VLAN. The mirrored data
grams will be attached with RSPAN tags.
Example:
Switch(config)#monitor session 1 remote vlan 5
66.3 monitor session reflector-port
Command:
monitor session <session> reflector-port <interface-number>
no monitor session <session> reflector-port <interface-number>
Function:
To configure reflector port, the no form of this command will delete the reflector port.
Parameter:
<session>: Session ID, range between 1~7, <interface-number>: Interface number.
Command Mode:
Global Mode.
Default:
Not configured.
Usage Guide:
This command configures the reflector port for the destination of mirror data grams, and disables
the MAC learning function of the specified port. The configuration of reflector port is to change the
mode of the local port from the destination port mode to be the reflector mode. Hence, the
configuration of reflector port and the destination port are exclusive. The no command is used to
restore the reflector port to normal port. The source port, in access or trunk mode, should not be
added to RSPAN VLAN. When the reflector port is configured as springboard of CPU TX direction
mirroring, it must be configured as TRUNK port and allows the RSPAN VLAN data passing, the
Native VLAN should not be configured as RSPAN VLAN.
Example:
Switch(config)#monitor session 1 reflector-port ethernet1/0/3

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
