6 FUNCTIONS OF THE OPERATION SCREENS CCW-R-2**B INSTRUCTION MANUAL
6-112
1. Press the [C1]/[C2] switching radio button to select the channel to be adjusted.
X Timing adjustment for the selected channel will be enabled.
2. Press each timing adjustment item to select the part to be adjusted.
3. Press or to adjust the timing value.
It is also possible to enter the timing value after pressing the [Entr Time] key .
If necessary, press the [Auto Cal.] pop-up key to select the auto calculation item.
4. To adjust other adjustment items, repeat steps 2 and 3.
To start each function in production, drain or full open lock, you can press the corresponding key at
this point to start the operation.
5. To finish the adjustment and return to the [Main Menu] screen, press the [Exit] key .
4 [Increase/Decrease] key (100ms) Increases/decreases a value in units of 100ms.
5 [Entr Time] key Sets the timing value directly from the [Numeric Keypad] screen.
6 [Auto Cal.] pop-up key Displays the auto calculation menu for the timing value.
[On]: Performs timing auto calculation.
[Off]: Does not perform timing auto calculation.
7 [C1]/[C2] switching radio button Selects the channel to be adjusted.
This is displayed only when weigher setting is C1+C2.
Table 6-53 Timing Adjustment Items
No. Item Name Function
1 WH-DS Sets the time from the discharge request signal input from the packer up to the
discharge completion signal output.
2 IS-WH Sets the time from the discharge request signal input from the packer up to the WH
(weigh hopper) operation start.
3 WH-PH Sets the time from the WH (weigh hopper) operation start up to the PH (pool hopper)
operation start.
4 PH-RF Sets the time from the PH (pool hopper) operation start up to the RF (feeder) operation
start.
5 STAGGER This item is available when the timing hopper is not used.
Used to prevent products from jamming in the packer. Sets the interval for discharging
when discharge of the selected head is divided into three times.
When not performing staggered discharge, set this item to 0msec.
6 WH-BH Sets the time from the WH (weigh hopper) outside operation start up to the BH
(booster hopper) operation start.
7 BH-WH Sets the time from the BH (booster hopper) operation start up to the WH (weigh
hopper) inside operation start.
Table 6-52 Items and Functions of Each Timing Adjustment Item(Continued)
No. Name Function
To Next Page
