4535 611 98931 iE33 Service Manual Page 118
CSIP Level 1 Installation: Peripheral Installations
a. In Association to Print, select a check box to allow printing to local and network
printers. If there is a check box selected, you cannot change the print settings using Edit
during a patient exam. When using Print, an image is sent to the printer and a copy of
the image to one of the system (SIP) hard drives.
b. In Association to Alt Print, select a check box to allow printing to the local printer.
When using Alt Print, images are not sent to the system (SIP) hard drives.
c. In Association to Report, select a check box to allow printing to a report printer using
Report.
Sony UPD-23MD Color Printer
The Sony UPD-23MD printer uses USB digital data. The printer has no switches and the control
settings are accomplished via software. The Philips-recommended settings are part of the system
disk image. The recommended control settings are listed in Table 5-6.
NOTE After the Sony UPD-23MD printer has been installed and connected to an AVIO RIP
USB connector, if the cable is connected to a different USB connector, the original
printer name in the Printer Setups menu may be replaced by the original printer
name appended with “Copy 1,” Copy 2,” or “Copy 3” (one name for each USB port on
the AVIO RIP). Although the printer will function correctly when connected to any of
the USB ports, the original printer name may be restored by reconnecting the printer
to the USB port that it was originally connected to.
