4535 611 98931 iE33 Service Manual Page 347
CSIP Level 1 Cabling: Cable Lists
453561182401 Cable Assy, SIP Power ON/STBY to Bulkhead Diagram: Figure 11-14
453561153802 Cable Assy, Stereo, Mic Out, Line In, Line Out Diagram: Figure 11-14
453561182491 Cable Assy, TGC/LGC Board, iE33 Diagram: Figure 11-14
Parts Info: Figure 14-20
453561182661 Cable Assy, Trackball Select Buttons, iE33 Diagram: Figure 11-14
Parts Info: Figure 14-20
453561153793 Cable Assy, Trackball to CPM USB, iE33 Diagram: Figure 11-14
Parts Info:
2275-0541-01 Cable Assy, Ultra ATA EIDE Diagram: Figure 11-14
453561153812 Cable Assy, USB, CPM to Keyboard Diagram: Figure 11-14
Parts Info: Figure 14-20,
Figure 14-22
453561153692 Cable Assy, USB, Host Bulkhead to User Diagram: Figure 11-14
Parts Info: Figure 14-13
Table 11-2 iE33 System Power Distribution Cables
Part Number Cable Description Notes/Reference
453561153492 Cable Assy, Acquisition Power Supply Diagram: Figure 11-15
453561182591 Cable Assy, AC Tray LED Diagram: Figure 11-15
453561182371 Cable Assy, AC Tray Primary Diagram: Figure 11-15
453561182381 Cable Assy, ATX Power Supply to LED Power Supply Diagram: Figure 11-15
